Cleanroom Extractions & Duct
The air extraction duct, integrated on the wall, is a spatially efficient solution for air extraction, given that additional ventilation structure, which around reduce space, is not necessary. the air extraction duct wall consists of aluminum profiles 100 mm wide, rock wool filters, 100 mm thick, and the final layer which can be made of powder coated aluminum, stainless stool, hpl synthetic stone. the empty intermediate space functioning as a ventilation duct, is reinforced by aluminum strips. an adequately sized stainless steel grid is integrated to enable the entrance of an into the air conditioning duct.
Modular Dimensions
WIDTH
HEIGHT
THICKNESS
UP TO 1200 MM
UP TO 4420 MM
UP TO 83 MM
1
2
3
4
FRAME STRUCTURE
CORE
FINAL LAYER
STAINLESS STEEL GRID
A
B
AIR EXTRACTION DUCT
FLOOR PROFILE
Composition Of Air-Extraction Duct
| Components | Material | Thickness/Dimensions |
|---|---|---|
| Frame Structure | Aluminium Profiles | T = 100 mm |
| Core | Rockwool 100 kg/m³ | T = 100 mm |
| Final Layer | Powder Coated Aluminium (60–80) | T = 1.2 mm |
| HPL | T = 4 mm | |
| Synthetic Stone (Kerrock) | T = 6 mm | |
| Stainless Steel* | T = 1 mm | |
| Stainless Steel Grid* | Stainless Steel* | Max H/W = 1100/100 |
| Ventilation Duct* | Reinforced With Aluminium Strips | Max H/W = 1100/4420/100 |
Reclean provides cleanroom doors and partition systems in compliance with the standards and design requirements of cleanrooms and controlled environments.
The type of cleanroom doors and partitions required depends on the process facility and its manufacturing and production standards.
Ozone’s state-of-the-art manufacturing setup and capable team enable it to fulfill such customized requirements for a wide and diverse customer base.
